Chogori offers several connector solutions suitable for LED street lighting applications, where high levels of waterproofing and resistance to temperature fluctuations are essential.

Recommended products include the M15 Series (10A), Mini Series 3 pin (5A), and Standard Series 2–8 pin (5–10A). These connectors feature IP67 or higher protection, providing reliable protection against rain and water exposure.

Their contacts are available with silver or gold plating, helping maintain low contact resistance and reliable electrical performance during long-term outdoor use. They are well suited for applications such as municipal street lighting and smart street-lighting poles.

For architectural lighting applications, connectors need to provide long-term outdoor durability, corrosion resistance, and reliable protection against water and dust. Chogori offers a range of suitable connector solutions, including:

Mini Series: 8 pin (8A)
Standard Series: 2–4 pin (10A)
Standard Series: 2+4 / 2+6 pin (10A + 2A / 5A + 2A)
Middle Series: 2–5 pin (10–20A)
Middle Series: 3+5 pin (15A + 2A)

These connectors feature weather-resistant housing materials and reliable sealing structures to withstand challenging outdoor conditions such as temperature fluctuations, rain, and UV exposure.

Their multi-pin integrated designs can handle multiple power and control signal circuits, simplifying wiring while improving overall system reliability. They are well suited for applications such as building facade lighting, architectural contour lighting, and landscape lighting projects.

Chogori offers a range of connector solutions suitable for LED display applications, where stable signal transmission, multi-pin integration, and quick mating are critical.

Recommended options include the Standard Series 8 pin (5A), Middle Series 2–3 pin (20A), Large 3+9 pin (20A + 5A), Large 2+13 pin (20A + 5A), and CAC3 Series (20A).

The hybrid multi-pin designs can support both power delivery and signal transmission in a single connector, helping ensure stable and synchronized display performance. Their modular design also enables fast installation and maintenance, making them well suited for the dense cabling requirements of indoor and outdoor LED displays, including stage rental screens and outdoor advertising displays.

Plant lighting applications place high demands on connectors in terms of water and dust protection, long-term reliability, and current-carrying capacity. Chogori offers several connector series suitable for these applications.

Recommended options include the Standard Series 2–3 pin (10A), Middle Series 2–3 pin (20A), and Large Series 2–3 pin (20A).

Designed for demanding and humid environments, these connectors provide reliable IP protection against moisture, water mist, and other harsh conditions. They are well suited for the power supply and control requirements of plant grow lights, with applications in greenhouses, vertical farms, and other controlled-environment agriculture systems.

Chogori connectors are available with a range of IP protection ratings to suit different operating environments.

Common waterproof ratings include IPX5, IPX6, and IPX7, providing protection against water jets and temporary immersion. For combined water and dust protection, available ratings include IP65, IP66, IP67, IP68, and IP69K, making them suitable for demanding environments such as outdoor industrial applications, vehicles, high-humidity and dusty conditions, and high-pressure cleaning.

Customers can select the appropriate IP-rated connector based on their specific application and environmental requirements.
