Rated Voltage: 48V AC / 60V DC
Rated Current: 40A Max
Withstand Voltage: 1,000V AC
Insulation Resistance: 100MΩ at DC 500V
IP Rating: IP67
OperatingTemperature: -40°C to 105°C
Salt Spray: 5% Nacl, 48H
Mating Cycle: 100 Cycles
Wire Gauge: 10AWG/5.0mm²
Flammability Rating: UL94V-0
