Rated Voltage: 300V DC
Rated Current: 20A+5A
Withstand Voltage: 2,000V AC
Insulation Resistance: 100MΩ at DC 500V
IP Rating: IP67 Mated
OperatingTemperature: -40°C to 105°C
Salt Spray: 5% Nacl, 48H
Mating Cycle: 500 Cycles
Wire Processing: Solder
Wire Gauge: 14AWG/Max, Signal 20AWG/Max
Flammability Rating: UL94V-0
