Rated Current: 20A+3A
Withstand Voltage: 1,200V AC
Insulation Resistance: 100MΩ at 500V DC
IP Rating: IP67 Mated
Operating Temperature: -40°C to 105°C
Salt Spray: 5% NaCl, 48H
Mating Cycle: 500 Cycles
Wire Processing: Solder
Wire Gauge: Power 12AWG/Max, Signal 20AWG/Max
Flammability Rating: UL94V-0
